Welded Hydraulic Cylinders

Introduction to Welded Hydraulic Cylinders

Welded hydraulic cylinders are known for their strength, durability, and compact design, making them ideal for a variety of heavy-duty industrial and mobile applications. These powerful components convert hydraulic energy into mechanical force, enabling equipment to lift, push, and pull heavy loads with precision and efficiency.

What Are Welded Hydraulic Cylinders?

Welded hydraulic cylinders are a type of actuator featuring a barrel with end caps welded directly to it, eliminating the need for tie rods. This design enhances strength, minimizes leaks, and allows for a more compact build. Key components include the cylinder barrel, piston, piston rod, and end caps, all working together to deliver reliable mechanical movement.

MYLER HYDRO is a leading manufacturer of high-performance welded hydraulic cylinders, trusted across industries for quality and innovation.

Applications of Welded Hydraulic Cylinders

Due to their rugged construction and reliable performance, welded hydraulic cylinders are widely used in several industries:

1. Construction Equipment：Utilized in machinery such as excavators, bulldozers, and loaders for tasks like lifting, digging, and pushing.
2. Agricultural Machinery：Essential in tractors, plows, and harvesters for lifting, positioning implements, and controlling movements.
3. Material Handling：Found in forklifts, pallet jacks, and loaders to facilitate efficient lifting and movement of goods.
4. Mining Operations：Powering heavy-duty equipment like crushers and drills, handling harsh conditions and intense pressure.
5. Industrial Machinery：Used in presses, compactors, and manufacturing systems to apply consistent and powerful force.
6. Marine Applications：Employed in steering systems and deck machinery, where they must endure corrosive environments and demanding loads.

Benefits of Using Welded Hydraulic Cylinders

1. Exceptional Durability：The welded design ensures fewer leak points and greater structural integrity, even under high stress and frequent use.
2. Compact Size：Ideal for equipment with limited space, the streamlined build supports powerful performance without a bulky footprint.
3. High-Pressure Capability：Built to handle extreme hydraulic pressure, welded cylinders are reliable under the toughest working conditions.
4. Customizable Solutions：These cylinders can be designed to meet specific performance, size, and material requirements for any application.

Custom Welded Hydraulic Cylinder Solutions

1. Exceptional Durability：The welded design ensures fewer leak points and greater structural integrity, even under high stress and frequent use.
2. Compact Size：Ideal for equipment with limited space, the streamlined build supports powerful performance without a bulky footprint.
3. High-Pressure Capability：Built to handle extreme hydraulic pressure, welded cylinders are reliable under the toughest working conditions.
4. Customizable Solutions：These cylinders can be designed to meet specific performance, size, and material requirements for any application.

Tailored to Your Needs

MYLER HYDRO offers fully customizable welded cylinders, ensuring every unit fits seamlessly into your system. Whether you need custom mounting options, specific stroke lengths, or specialized materials, our team delivers precision-engineered solutions.

Industry-Specific Designs

Every industry has unique demands. MYLER HYDRO provides tailored solutions for construction, mining, agriculture, marine, and more—each designed for optimal performance in your specific environment.

Why Choose MYLER HYDRO?

Expertise & Experience

With decades of industry knowledge, our skilled engineers and technicians manufacture cylinders that meet the highest standards of reliability and performance.

Advanced Technology

We utilize the latest manufacturing technologies to deliver efficient, durable, and innovative hydraulic solutions.

Uncompromising Quality

Rigorous quality control and a commitment to excellence ensure every MYLER HYDRO cylinder exceeds expectations.

MYLER HYDRO :

Exceptional Welded Cylinders

Why Choose Us?

Our cylinders power productivity across countless sectors—from fields and factories to mines and marine vessels. With an ongoing commitment to innovation and customer satisfaction, MYLER HYDRO continues to lead the way in hydraulic cylinder manufacturing.

Customer Testimonials

“MYLER HYDRO provided us with high-quality welded hydraulic cylinders that significantly enhanced our equipment’s performance. Their attention to detail and customer service were outstanding.”

Dimension Table for Welded Cylinder

Bore	A	B	C	D	D1	D2	E	F	G	H	J	K	L	M	N	P
1.5”	ø 0.875”	Ø1.875”	241	Ø19.3	Ø45	Ø46	38	63.5	69.5	3/4″- 16UNF	23.5	52	38	20	47	9/16- 18UNF
2”	Ø1.125”	Ø2.375”	311	Ø25.5	Ø54	Ø50.8	50.8	84.5	95.7	1.0″- 12 UNF	29	66.7	54	29	62.4	3/4″- 16UNF
2.5”	Ø1.5”	Ø2.875”	311	Ø25.5	Ø54	Ø50.8	50.8	84.5	95.9	1.1/8″- 12 UNF	29	66.7	54	29	62.4	3/4″- 16UNF
3.0”	Ø1.5”	Ø3.375”	311	Ø25.5	Ø54	Ø50.8	50.8	84.5	89.5	1.1/8″- 12 UNF	29	66.7	47.6	29	66.6	3/4″- 16UNF
3.5”	Ø1.75”	Ø3.875”	311	Ø25.5	Ø64	Ø50.8	55	84	88	1.3/8″- 12 UNF	29	72	47.6	29	66.6	3/4″- 16UNF
4.0”	Ø2.0”	Ø4.5”	311	Ø25.5	Ø64	Ø63.5	55	84	89	1.3/8″- 12 UNF	29	72	44.5	29	66.6	3/4″- 16UNF

What types of hydraulic cylinders do you manufacture?

We manufacture a wide range of hydraulic cylinders, including but not limited to, single-acting cylinders, double-acting cylinders, telescopic cylinders, and custom-designed cylinders for specialized applications. Our products are suitable for various industries, ensuring a versatile and reliable solution for different needs.

Can you customize hydraulic cylinders to our specifications?

Absolutely! We specialize in providing customized hydraulic cylinders tailored to your specific requirements. Whether you need unique dimensions, pressure ratings, or special materials, our experienced engineering team works closely with you to ensure the design meets your exact specifications.

Which industries do you serve?

We serve a broad spectrum of industries, including construction, agriculture, mining, manufacturing, marine, automotive, and energy. Our hydraulic cylinders are designed to perform in demanding environments, offering reliable solutions for both heavy-duty and precision applications.

How do you ensure the quality of your hydraulic cylinders?

Quality is at the core of everything we do. Our hydraulic cylinders undergo rigorous testing and quality control processes, including pressure testing, material inspections, and dimensional checks. Additionally, we use high-grade materials and the latest manufacturing technologies to ensure each product meets the highest industry standards and exceeds customer expectations.
